START-UP MODE:
Run the ROM Bootloader
HOST DEBUGGER CONNECTION (if activated):
Network connection
NETWORK INTERFACE PARAMETERS:
TMS is present
Use Message Exchange to download image
LAN IP address will be obtained from bootp.
HARDWARE PARAMETERS:
Serial channels will use a baud rate of 9600
Processor: MPC8260 (Mask 0x24), PPC_clk = 198MHz, CPM_clk = 165MHz
SDRAM : 64MB, cycle time 8.0ns @ Cas Latency=3
This board's Ethernet hardware address is 00:80:01:D0:08:B1
SOFTWARE WATCH DOG TIMER STATUS:
The watch dog timer is DISABLED and will NOT timeout.
MXD BOOT LOADER PARAMETERS :
The download file will come from the TMS
STARTUP DELAY:
After board is reset, start-up code will wait 5 seconds
--------------------------------------------------------------------------
To change any of this, press Enter, Return, or space key within 5 seconds
The settings shown in the preceding sample are correct for a DCC boot ROM. If your settings are
not correct, perform the steps shown in the following sample output.
To change any of this, press any key within 5 seconds
(M)odify any of this or (C)ontinue? [M] m
For each of the following questions, you can press <Return> to select the value shown in
braces, or you can enter a new value.
How should the board boot?
1. pROBE+ standalone mode
2. pROBE+ waiting for host debugger via serial connection
3. pROBE+ waiting for host debugger via a network connection
4. Run the Application
Which one do you want? [4] 4
NETWORK INTERFACE PARAMETERS:
Enter 0 if TMS absent
Enter 1 if TMS present and you'd like to TFTP the image
Enter 2 if TMS is present and you'd like to use the MXD to get the image
: [2] 2
Do you want a LAN interface? [Y] y
BOOTP, RARP or FIXEDIP can obtain this Board's IP.
The default method is TFTP
Enter Y to change the default [N] y
Enter 0 for RARP, 1 for BOOTP, 2 for FIXED [1] 1
New configuration is: BOOTP
Use a subnet mask for the LAN interface? [N] n
Should there be a default gateway for packet routing? [N] n
HARDWARE PARAMETERS:
Baud rate for serial channels [9600]
Do you want to change the board's clock rate? [N] n
Do you want to change the SWT status? [N] n
Do you want to change the board's Ethernet address? [N] n
ROM BOOTLOADER PARAMETERS:
STARTUP DELAY:
How long (in seconds) to delay before starting up? [5]
----------------------------------------------------------
STARTUP MODE:
Run Application
NETWORK INTERFACE PARAMETERS:
TMS is present
