Avaya Media Processing Server 500 Hardware Installation And Maintenance page 138

Operation and Administration
Figure 36: TMS Front Panel
Table 7: TMS Front Panel Connectors and Indicators
Item
AUDIO connector
CONSOLE connectors
LEDs 0 - 15
Microswitches
HUB LEDs (See
Ethernet Hub
Indicators on
page 139.)
Span connector
Remote terminal connector
Ethernet connection A
Other connectors and
indicators
Avaya Media Processing Server 500 Hardware Installation and Maintenance
138
Description
RJ11 jack for connecting a telephone handset to audibly monitor an MPS
500 line. (See
RS232 (9-pin DIN) port for connecting a debug terminal. Used for boot
ROM and diagnostics. (See
page 123 and
Provide diagnostic indications on startup. (See
Sequence on page 128.)
Reserved for future enhancement.
COL Indicates errors or collisions in HUB.
LNK Indicates link status.
FDX Indicates full duplex mode status.
ACT Indicates activity status.
DCC Front Panel
RJ-48M 50-pin connector connects up to eight digital spans (T1 or E1) to
PSTN. (See Telephony Interfaces
RS232 (9-pin DIN) port for connecting a debug terminal. Used for boot
ROM and diagnostics. (See
page 123 and
100 MB connection for Speech LAN
Reserved for future enhancement.
Comments? infodev@avaya.com
Ethernet Hub Indicators on page 139.)
Verifying and Modifying Boot ROM Settings
Debug Terminal Connection Settings
on page 195.)
Verifying and Modifying Boot ROM Settings
Debug Terminal Connection Settings
on page 134.)
TMS Startup LED
on page 134.)
October 2014
on
on
