Maintenance
Installing a TMS
1. Install the modules on the TMS in the same slots from which they were removed. Install
modules in slots 2 and 4 first:
a. Carefully mate the connector of the module board with the connector on the TMS riser
board.
b. Install two screws to secure the module mounting plate to the TMS front panel.
2. Slide the TMS into the chassis on slot guides and seat the backplane connectors by pushing
in on the two card extractors.
3. Secure the TMS to the chassis with two screws.
4. Connect the telephone line input cable to the RJ48M connector on the front of the DCC.
Avaya Media Processing Server 500 Hardware Installation and Maintenance
186
Comments? infodev@avaya.com
October 2014
