NETWORK INTERFACE PARAMETERS:
TMS is present
Use Message Exchange to download image
LAN IP address will be obtained from bootp.
HARDWARE PARAMETERS:
Serial channels will use a baud rate of 9600
Processor: MPC8260 (Mask 0x24), PPC_clk = 198MHz, CPM_clk = 165MHz
SDRAM : 64MB, cycle time 8.0ns @ Cas Latency=3
This board's Ethernet hardware address is 00:80:01:D0:08:B1
SOFTWARE WATCH DOG TIMER STATUS:
The watch dog timer is DISABLED and will NOT timeout.
MXD BOOT LOADER PARAMETERS :
The download file will come from the TMS
STARTUP DELAY:
After board is reset, start-up code will wait 5 seconds
--------------------------------------------------------------------------
To change any of this, press Enter, Return, or space key within 5 seconds
3. Verify that the watch dog timer is DISABLED in the ROM.
4. Verify the rest of the settings. If all the setting are correct, select Continue by typing c.
(M)odify any of this or (C)ontinue? [M] m
5. To modify the current settings, type m:
a. Press <RETURN> to accept the current values you do not want to change.
b. To change the value of an item, type the new value after the prompt. Continue until the
system boot is complete.
For each of the following questions, you can press <Return> to select the value
shown in braces, or you can enter a new value.
How should the board boot?
1. pROBE+ standalone mode
2. pROBE+ waiting for host debugger via serial connection
3. pROBE+ waiting for host debugger via a network connection
4. Run the Application
Which one do you want? [4]
NETWORK INTERFACE PARAMETERS:
Enter 0 if TMS absent
Enter 1 if TMS present and you'd like to TFTP the image
Enter 2 if TMS is present and you'd like to use the MXD to get the image
: [2]
Do you want a LAN interface? [Y]
BOOTP, RARP or FIXEDIP can obtain this Board's IP.
The default method is FIXED
Enter Y to change the default [N]
The current LAN IP address is [192.168.101.5]
Use a subnet mask for the LAN interface? [N]
Should there be a default gateway for packet routing? [N]
HARDWARE PARAMETERS:
Baud rate for serial channels [9600]
Do you want to change the board's clock rate? [N]
Do you want to change the SWT status? [N]
Do you want to change the board's Ethernet address? [N]
ROM BOOTLOADER PARAMETERS:
STARTUP DELAY:
How long (in seconds) to delay before starting up? [5]
a. The original verify screen displays the new values. To make additional changes, select
Modify again. To save the changes, select Continue.
