Chapter 10 First-Time Setup
Using the IP address displayed in the Cisco IP telephone welcome message, log in to the CTS
Step 1
Administration software.
From Troubleshooting, choose Hardware Setup to initially set up the components in the
Step 2
Cisco TelePresence system. Cisco suggests that you set up CTS components in the following order:
•
•
•
•
•
•

Setting Up the Displays

A display is set up correctly when the color on the display has been adjusted for the lighting in the
meeting room. Each display must be set up individually.
•
•
Each display in the meeting room should now be showing a set of horizontal grey bars and that display's
relative position. Select the color temperature of the lighting in the meeting room and click Apply.
Selecting the Light Level
When adjusting the images on the display screens for the Cisco TelePresence system, you must take the
color temperature of the ambient light in the room into consideration.
Sources of light in most rooms are either incandescent light bulbs that use tungsten filaments or
fluorescent lights. Each of these light sources, and the amount of light in terms of lumens or watts,
produces a different color temperature. This color temperature is sometimes expressed using terms such
cool, warm, or daylight, but can be expressed more precisely in kelvins (K) as a numeric value.
Following are the temperatures that can be selected for adjusting the image on the Cisco TelePresence
display screens:
•
•
•
•
•
In many cases, the color temperature is printed on the light bulb. If you are unable to ascertain the type
and color temperature of light bulbs in the meeting room, experiment with color temperature settings
until the color and images on the display screen look lifelike.
OL-14521-01
Setting Up the Displays, page 10-5
Setting Up the Cameras, page 10-6
Setting Up the Speakers, page 10-13
Setting Up the Microphones, page 10-13
Setting Up the Projector, page 10-14
Other Devices, page 10-18
From the Hardware Setup page under Troubleshooting, click the Display radio button.
Click Start to begin the adjustment process.
3500 K
4000 to 4100 K (recommended setting)
5000 K
6500 K
7500 K
Setting Up CTS Components
Cisco TelePresence System 3200
10-5
