Building the Lighting Assembly

Revised: July 28, 2008, OL-14521-01
Parts List
Key Part Description
1 Lighting support brackets
2
Support struts
3 End structure brackets
4 Plastic diffuser panel: center
5 Plastic diffuser panel: ends
6
Plastic diffuser panel: top right
7 Plastic diffuser panel: top left
8 L-bracket
9 Metal trim panel: center left
10
Metal trim panel: top side
11 Metal trim panel: end
12 Metal trim panel: center right
13 Reflector bottom tray: center
14
Reflector bottom tray: left side top
15 Reflector bottom: left end
16 Reflector bottom spacer
17 Reflector top: center
18
Reflector top: top side
19 Reflector top: end
20 Reflector transition piece: left
21 Reflector transition piece: right
22
Reflector transition piece: corner
OL-14521-01
C H A P T E R
Part Number Qty Ctn Notes
700-23749-xx 6
700-23752-xx 6
700-23750-xx 4
700-23745-xx 1
700-23746-xx 2
700-23747-xx 1
700-23748-xx 1
700-23899-xx 4
700-24126-xx 1
700-23897-xx 2
700-23898-xx 2
700-23896-xx 1
700-23826-xx 1
700-23827-02 1
700-23828-02 1
700-24152-xx 2
700-23731-xx 1
700-23734-xx 2
700-23735-xx 2
700-23756-xx 1
700-23757-xx 1
700-23758-xx 2
4
49
49
49
49
49
49
49
49
49
49
49
49
49
49
49
49
49
49
49
49
49
49
