Chapter 7
Building the Second Row Table Assembly
Parts List
Step 19
Join table section 4 to table section 2 using the draw bolts and spline.
If you are building a Reduced Configuration table (four tabletops instead of six), continue to
Step 22
Note
after completing this step.
Figure 7-19
Tabletop Section 4
17
40
39
Cisco TelePresence System 3200
7-22
OL-14521-01
