Replacing a First Row Table Top Section

Tip The projector screen comes with printed instructions that should assist you with replacing it. If you
cannot find the instructions, reverse the order of removal to install it.
Power on the system by completing the steps in the
Step 19
Replacing a First Row Table Top Section
Complete these steps to replace a first row table top section.
Required Information, Tools, and Equipment
To remove and replace a first row table top section, you need the following tools:
•
•
A 10 mm open end ratcheting wrench is useful to loosen and tighten the draw bolts.
Tip
Make sure to retain all screws, connectors, and other parts during the disassembly.
Note

Removing and Replacing a First Row Table Top Section

Step 1 Open the table door.
Perform the following actions for specific first-row table top sections:
Step 2
•
•
Step 3 Detach the microphone from the table top section to be replaced. See
diagram of the microphone and its attachment hardware.
Step 4 Disconnect the microphone from the audio/video expansion unit, route the cable through the table top
section, and remove the microphone.
Remove the privacy panel from the table top section to be replaced.
Step 5
Chapter 6, "Building the First Row Table Assembly"
Tip
Remove the screws from the table legs that support the table top section.
Step 6
Move one of the table legs to allow access to the draw bolts.
Step 7
Cisco TelePresence System 3200
12-22
Medium and large Phillips screwdriver
10 mm wrench
If you are replacing the table door or the left-center table top section, remove the table door. See
Figure 6-14 for an exploded diagram of the parts for the door.
If you are replacing the center table top section, remove the projector. See
exploded diagram of the projector assembly.
Chapter 12
"Powering On the System" section on page
Figure 6-13
has exploded drawings of the privacy panels.
Field-Replaceable Unit Guide
12-1.
Figure 8-3 for an
for an exploded
