Chapter 2
Building the Display Assembly
Parts List
Step 6
Attach the Camera Assembly bracket to the center Display structure, making sure that this structure uses
the larger codec tray.
Figure 2-6
Camera Assembly bracket
9
13
13
1
The Camera Assembly bracket attaches to the center Display structure.
Note
Cisco TelePresence System 3200
2-7
OL-14521-01
