Replacing a Plasma Display—Part Number CTS-DISP-65-GEN2
Step 7 Reattach the Ethernet and signal cables according to your temporary markings.
Do not attach the camera hoods at this time.
Step 8 Power on the system by completing the steps in the
Perform the camera adjustment procedure and, if required, refocus and realign the camera.
Step 9
See the
Re-attach the camera hood and lens hood.
Step 10
Replacing a Plasma Display—Part Number CTS-DISP-65-GEN2
Required Information, Tools, and Equipment
To replace a display, you need the following information, tools, and equipment:
•
•
Uncrating and unpacking:
•
•
•
•
•
•
•
Cisco TelePresence 3200 Structure, Accessory, and Adjustment Assembly:
•
Tip
•
•
•
•
•
•
•
Cisco TelePresence System 3200
12-4
"Setting Up the Cameras" section on page 10-6
Release Notes for Cisco TelePresence System, Release 1.4, OL-12074-05
Cisco TelePresence System Release 1.4 Administrator's Guide, OL-13676-03
Claw hammer or small pry bar
Large Phillips screwdriver
* Tin snips
* Pallet jack or hand cart (for moving components)
* Safety gloves
* Safety glasses
* Box cutters
Power screwdriver with 2.5, 3, and 6 mm (standard or round) Allen bits, or standard 2.5, 3, and 6 mm
Allen wrenches
A round-head Allen bit allows the bit to work at an angle instead of only straight out, which is
helpful in tight spots.
Manual screwdrivers, Phillips and flat head types
Metric wrenches, 10 to 15 mm
9/64-inch Allen wrench (supplied with speakers)
0.9mm Allen wrench for camera lens adjustments (if the lens uses a thumbscrew no tools are
required)
Level
Masking tape
* Tie wraps
