Appendix A Appendix A: Parts List Sorted by Carton
Carton 44 of 58: Lighting Assembly, 69-1613-xx,
CTS3K-LIGHT-STR
Sub-Kit ID
Kit ID Number Number
69-1613-xx
Carton 45 of 58: Projector Bracket, 69-1631-xx,
CTS3K-STRUCTURE
Sub-Kit ID
Kit ID Number Number
69-1631-xx

Carton 46 of 58: Projector Screen, 74-5416-xx, CTS3K-SCREEN

Sub-Kit ID
Kit ID Number Number
74-5416-xx
1. Refer to the installation guide that is packaged with the assembly to install the projector screen.
Carton 47 of 58: Accessory Cabinet, Right, 69-1837-xx,
CTS3K-M-TABLE-G2
Sub-Kit ID
Kit ID Number Number
69-1837-01
OL-14521-01
Part Number Part Description
700-23756-xx Reflector transition piece: left
700-23757-xx Reflector transition piece: right
700-23758-xx Reflector transition piece: corner
Part Number Part Description
48-1963-01 M6 x 10 mm screws
700-23824-xx Projector mounting bracket
Part Number Part Description
Projector screen assembly
Part Number Part Description
74-5297-01 Accessory cabinet, Right
Carton 44 of 58: Lighting Assembly, 69-1613-xx, CTS3K-LIGHT-STR
Cisco TelePresence System 3200
Chapter Parts List
Qty Reference
1 Chapter 4
1 Chapter 4
1 Chapter 4
Chapter Parts List
Qty Reference
4 Chapter 7
1 Chapter 7
Chapter Parts List
Qty Reference
1
1 Chapter 7
Chapter Parts List
Qty Reference
1 Chapter 5, 6
A-15
