Parts List
Step 4
Assemble the I/O modules for the inner molded foam bumpers.
Figure 6-4
Note
Steps for routing the Ethernet and power cables are in
Note
The flange on the I/O module cover place is wider on the bottom than on the top.
Cisco TelePresence System 3200
6-6
Foam Bumper Assembly
25
21
19
20
Chapter 6
Building the First Row Table Assembly
22 23 24
Chapter 9, "Routing Power and Signal Cables."
OL-14521-01
