Chapter 7 Building the Second Row Table Assembly
Key Part Description
43
I/O blank: large
44 I/O blank: small
45 I/O modules: power/Ethernet
46
I/O Module Cover plate
47 Cat6 Ethernet cord
48
3 m Jumper cord
49 M4 nuts
50 M4 x 12 mm screws, black
51 Microphone
52
M4 x 30 mm screws
53 M4 washers
54 Power distribution units
55 Screws
56
M8 shoulder screws for Floating
Brackets
Microphone extension cords, 9.5M
Touch-up paint, dark gray
Touch-up paint, dark gray
The table segments are unstable during assembly. Use caution, and support all structures as required.
Caution
Warning Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Table elements are heavy, and metal edges can be very sharp. Protect your hands and eyes from injury
Caution
by wearing safety gloves and glasses.
OL-14521-01
Part Number Qty
69-1830-01 2
700-23807-01 14
74-xxxx-xx 12
700-23305-01 7
37-0887-02 (3M) 1
37-0901-01 (10M) 8
37-0965-01 (12M) 3
37-0833-01 9
49-0326 20
48-2426-01 10
74-4743-01 6
74-4787-01 2
To be provided 1
69-1880-01 28
48-2437-01
37-0931-01 6
79-2269-01 1
95-10160-01 1
Ctn Notes
1
1
1 Part number changes per country. Refer
to "Appendix B: Region- and
Country-Specific Equipment"
number.
50-
54
1
1
1
1
1
1 Included in Microphone kit.
1 Included in Microphone kit.
1 Chapter 7, 8
1
21
1 Attach these cords to the microphone
cables to reach the audio/video extension
unit.
1 Use this to cover any imperfections for
the privacy panel that are caused by
assembly, shipping or handling.
1 Use this to cover any imperfections for
the privacy panel that are caused by
assembly, shipping or handling.
