Chapter 7
Building the Second Row Table Assembly
Parts List
Step 40
Attach the privacy panel for section 2 to the table assembly.
Align the panels so that the seam between privacy panels 1 and 2 is aligned with the table top seam for
Note
table tops 1 and 2.
Figure 7-40
Section 2 Privacy Panel
28
38
Cisco TelePresence System 3200
7-40
OL-14521-01
