Chapter 4
Building the Lighting Assembly
Step 7
Attach the left and right (vertical) Reflector Bottom ends to the End Structure brackets and attach the
compliance sticker to the left reflector bottom end.
Figure 4-7
Left and Right (vertical) Reflector Bottom ends
3
15
27
27
30
OL-14521-01
33
Cisco TelePresence System 3200
Parts List
4-9
