Chapter 7
Building the Second Row Table Assembly
Parts List
Step 20
Place the left tabletop section 5 on the table assembly and join it to the section 3 tabletop using the draw
bolts and spline.
Figure 7-20
Tabletop Section 5 (Left)
18
40
39
Cisco TelePresence System 3200
7-23
OL-14521-01
