Replacing a Light Fixture—Part Number CTS-LIGHT-FIXT
Step 8 Attach the privacy panels to the table sections.
Note
If required, replace the cable cover for the right end privacy panel as shown in
Step 9
ties to bundle the microphone cable with other cables.
Step 10 Test the microphone by performing the procedures in the
page
Replacing a Light Fixture—Part Number CTS-LIGHT-FIXT
Required Information, Tools, and Equipment
To disassemble and reassemble portions of the Cisco TelePresence 3200, you need the following
information, tools, and equipment:
•
•
Tip
•
•
•
•
•

Replacement Bulbs

A Field Replacement Unit consisting of three 5-foot and two 4-foot 4100 K bulbs is available from Cisco
Customer Service. The part number is CTS-3000-BULBS.
If one or more bulbs need replacement, it is recommended that all five bulbs are replaced for lighting
uniformity.
Note The light fixtures installed during assembly have a 4100 K rating. If you set the Plasma display to
another value you need to purchase and replace the light fixtures to match the new color temperature
setting.
Cisco TelePresence System 3200
12-14
If required, adjust the privacy panel sections so that there is an equal amount of space between
each section.
10-13.
Cisco TelePresence System Release 1.4 Administrator's Guide, OL-13676-03
Power screwdriver with 2.5, 3, and 6 mm (standard or round) Allen bits, or standard 2.5, 3, and 6 mm
Allen wrenches
A round-head Allen bit allows the bit to work at an angle instead of only straight out, which is
helpful in tight spots.
Manual screwdrivers, Phillips and flat head types
Metric wrenches, 10 to 15 mm
Masking tape
Step stool or small step ladder
Laptop computer attached to network (for troubleshooting or reference)
Chapter 12 Field-Replaceable Unit Guide
Figure 7-46
"Setting Up the Microphones" section on
and add cable
