Chapter 7 Building the Second Row Table Assembly
Parts List
Step 11 Assemble the I/O modules for the outside left and outside right molded foam bumpers.
The outside left and outside right molded foam bumpers only have one I/O module each. The inner
molded foam bumpers have two (see Figure 7-12).
Figure 7-11 Foam Bumper Assembly
46
43
50
47 48 49
44
45
