Chapter 7
Building the Second Row Table Assembly
Step 12
Assemble the I/O modules for the inner molded foam bumpers.
The Ethernet cables are of different lengths. Attach the Ethernet cables to the I/O modules as follows:
Note
Use the 12M cable, 37-0965-01, for the I/O modules between sections 6 and 5
Use the 3M cable, 37-0887-02, for the I/O modules between sections 5 and 7
Steps for routing the Ethernet and power cables are in
Note
The flange on the I/O module cover piece is wider on the bottom than on the top.
Note
Figure 7-12
OL-14521-01
Foam Bumper Assembly
50
46
44
45
Chapter 9, "Routing Power and Signal Cables."
47 48 49
Cisco TelePresence System 3200
Parts List
7-15
