Chapter 10
First-Time Setup
Setting Up the Speakers
The speakers are set up correctly you can hear sound clearly from each one. You can choose whether you
want to cycle through the speakers automatically or manually.
•
•
•
•
Troubleshooting Speakers
Use
Table 10-3
Problem
No sound is heard.
Cisco TelePresence 3000/3200 only
Sound heard at wrong speaker.
Sound is not synchronized with
video.
Setting Up the Microphones
The microphones are set up correctly when each microphone registers sound. You must supply sound at
each microphone to complete setup.
The Microphone Troubleshooting screen displays the number of microphones available for testing. For
You will see three screens with either two of three microphones per screen, depending on the number of
microphones installed. The top microphone represents the microphone in the front row; the bottom
microphone icons represent the back row microphones.
•
•
•
OL-14521-01
Click Speakers on the Hardware Setup window to select the speaker test.
Click Start to begin the speaker setup.
Click Cycle Through Speakers to have sound cycled automatically for 5 seconds on each speaker.
Click Manually Step Through Speakers to test sound on each speaker. Click Next Speaker to
progress to the next speaker.
Table 10-3
to troubleshoot problems with speakers.
Troubleshooting Chart for Speaker Problems
Click Microphones on the Hardware Setup window.
Click Start to begin setup.
Lightly tap each microphone and watch the audio meter on the corresponding display screen to see
that sound registers.
Possible Cause
Speaker cable is not connected
or is only partially connected.
Speaker cable is not connected in
the correct connector.
—
Setting Up CTS Components
Possible Solution
Check that the red and black
pronged ends of the speaker
cable are securely fastened under
their corresponding connectors
on the speaker.
Check that the speaker cable is
plugged into the correct receptor
on the primary codec.
Tug on the plug to see if it is
fully plugged in. Press the plug
in firmly until a click is heard.
Check that the speaker cable is
plugged into the correct receptor
on the primary codec. Plug all
speakers into the primary codec.
Contact Cisco technical support.
Cisco TelePresence System 3200
10-13
