Chapter 4
Building the Lighting Assembly
Parts List
Step 8
Attach the Light Cup bracket to the left and right (vertical) Reflector Bottom ends.
Figure 4-8
Light Cup bracket
23
15
27
Cisco TelePresence System 3200
4-10
OL-14521-01
