Chapter 7 Building the Second Row Table Assembly
Parts List
Step 39 Lift the privacy panel for table section 1 into position until it seats on the locating pins on the table
assembly; then, use the plastic knob screws to loosely attach the privacy panel from below.
Do not fully tighten the screws until you attach all privacy panels. You perform final spacing adjustments
Note
after you attach the last panel.
Figure 7-39 Section 1 Privacy Panel
27
38
