Carton 12 of 58: Camera Assembly Bracket, 69-1627-xx, CTS3K-STRUCTURE
Carton 12 of 58: Camera Assembly Bracket, 69-1627-xx,
CTS3K-STRUCTURE
Sub-Kit ID
Kit ID Number Number
69-1627-xx
Carton 13 of 58: Brackets, 69-1632-xx, CTS3K-STRUCTURE
Sub-Kit ID
Kit ID Number Number
69-1632-xx
1. These brackets are for an optional Ethernet switch; if you did not order this option, disregard these parts.
Carton 14 of 58: Privacy Panel, Right Wing, 69-1628-xx,
CTS3K-STRUCTURE
Sub-Kit ID
Kit ID Number Number
69-1628-xx
Carton 15 of 58: Front Foot Stabilizer, 69-1624-xx,
CST3K-STRUCTURE
Sub-Kit ID
Kit ID Number Number
69-1624-xx
Cisco TelePresence System 3200
A-6
Part Number Part Description
700-23346-xx Camera assembly bracket
Part Number Part Description
700-23338-xx Switch bracket, left
700-23342-xx Codec attachment brackets
700-23344-xx Switch bracket, right
700-23345-01 Connecting plates
700-23363-xx Display tilt bracket
700-23426-xx Projector screen clips
700-23944-xx Speaker board brackets
Part Number Part Description
700-23362-xx Privacy panel: right wing
Part Number Part Description
700-23359-xx Front foot stabilizer
