Replacing a Speaker—Part Number CTS-LDSPKR
Step 19 Perform the display adjustment procedure.
See the
If you moved the camera, complete the following steps:
Step 20
a.
b.
Repackage the old display using the new display box and packing materials.
Step 21
Replacing a Speaker—Part Number CTS-LDSPKR
Required Information, Tools, and Equipment
To remove and replace a speaker for the Cisco TelePresence 3200, you need the following information,
tools, and equipment:
•
•
Tip
•
•
•
•

Removing and Replacing a Speaker

Make sure to retain all screws, connectors, and other parts during the disassembly.
Note
Take care not to mar the surface nor introduce smudges or dirt to the surface of the projector screen.
Caution
Power off the system by completing turning off the following units:
Step 1
•
•
Cisco TelePresence System 3200
12-8
"Setting Up the Displays" section on page 10-5
Perform the camera adjustment procedure and, if required, refocus and realign the camera.
See the "Setting Up the Cameras" section on page 10-6
Attach the camera hood and lens hood.
See Chapter 8, "Assembling the Remaining Cisco TelePresence Elements."
Cisco TelePresence System Release 1.4 Administrator's Guide, OL-13676-03
Power screwdriver with 2.5, 3, and 6 mm (standard or round) Allen bits, or standard 2.5, 3, and 6 mm
Allen wrenches
A round-head Allen bit allows the bit to work at an angle instead of only straight out, which is
helpful in tight spots.
Manual screwdrivers, Phillips and flat head types
Metric wrenches, 10 to 15 mm
9/64-inch Allen wrench (supplied with speakers)
Laptop computer attached to network (for troubleshooting or reference)
The two left PDUs on the left accessory cabinet
The single right PDU on the right accessory cabinet
Chapter 12 Field-Replaceable Unit Guide
for more information.
for more information.
OL-14521-01
