Replacing the Camera Cluster—Part Number CTS3K-CAM-CLST-G2
b.
Step 2 Power on the Cisco TelePresence 3200 by turning the power switches to the On position on the two left
PDUs, single right PDU, and auxiliary control unit.
Six check boxes display on the lower left corner of the center display screen.
Step 3 Wait while the system checks each check box and clears the screen.
The system IP address displays on the lower right corner of the center display screen.
Write down the IP address. This is the address of the primary codec.
Step 4
Log in to the system by entering the following information:
Step 5
a.
b.
Note
Click Login.
Step 6
Verify the status of the Cisco Unified Communications Manager (seen in the lower left portion of the
Step 7
window) is Enabled/Up.
Select Hardware Setup to verify the cameras, displays, speakers, and microphones are working
Step 8
properly.
If you are replacing a primary codec, perform the following steps:
Step 9
Note
a.
b.
c.
Replacing the Camera Cluster—Part Number
CTS3K-CAM-CLST-G2
Required Information, Tools, and Equipment
To remove and replace the camera cluster for the Cisco TelePresence 3200, you need the following
information, tools, and equipment:
•
•
Cisco TelePresence System 3200
12-2
Change the device MAC address to the MAC address for the new primary codec. The MAC address
should be displayed on the codec.
In the Admin field, type admin.
In the Password field, type cisco.
If your administrator has changed the user name or password, enter those values.
If you are not replacing a primary codec, do not perform the following steps.
Navigate to the Device Information > Configuration > CUCM settings window, then perform the
following actions:
In the Certificate Trust List (CTL) area, delete the CTL from your system by clicking Delete CTL.
In the Use Configuration TFTP Server area, click Automatic to set TFTP conditions to their default
value and remove any alternate TFTP servers.
Cisco TelePresence System Release 1.4 Administrator's Guide, OL-13676-03
Release Notes for Cisco TelePresence System, Release 1.4, OL-12074-05
Chapter 12 Field-Replaceable Unit Guide
OL-14521-01
