Chapter 4 Building the Lighting Assembly
Step 23 Attach the two Metal Trim panels to the L-brackets attached to the two (vertical) Plastic Diffuser panels.
Figure 4-23 Two Metal Trim panels
5
27
11
Install the codecs before you continue to the next chapter. See
Note
"Assembling the Remaining Cisco TelePresence Elements"
"Building the Display Shelf Assembly"
These Metal Trim panels cover the access opening used to route cables. You may not want to attach these
Note
Metal Trim panels until you complete the cable routing in
Cables."
OL-14521-01
Step 5
to install the codecs; then see
to continue the installation.
Chapter 9, "Routing Power and Signal
Cisco TelePresence System 3200
Parts List
11
through Step 8 in Chapter 8,
Chapter 5,
