Replacing a Codec Unit—Part Number CTS-CODEC-PRI-G2 (Primary Codec) or CTS-CODEC-SEC (Secondary Codec)
Replacing a Codec Unit—Part Number CTS-CODEC-PRI-G2
(Primary Codec) or CTS-CODEC-SEC (Secondary Codec)
Required Information, Tools, and Equipment
To remove and replace a codec unit for the Cisco TelePresence 3200, you need the following
information, tools, and equipment:
•
•
Tip
•
•
•
•

Removing and Replacing a Codec

Make sure to retain all screws, connectors, and other parts during the disassembly.
Note
Power off the system by completing turning off the following units:
Step 1
•
•
•
Make sure all system power is turned off before beginning this disassembly.
Caution
From the back of the Cisco TelePresence 3200, access the codec to be removed. Turn the power switch
Step 2
on the codec to the Off position.
Remove all cable ties holding the cables to the cable management bar. Take note of the organization of
Step 3
the cables.
Step 4 Remove the cables from the codec. Label each cable with masking tape for identification as it is
removed.
See
Remove and retain the screws that attach the codec's L-brackets to the Display structure Front feet.
Step 5
See
Cisco TelePresence System 3200
12-10
Cisco TelePresence System Release 1.4 Administrator's Guide, OL-13676-03
Power screwdriver with 2.5, 3, and 6 mm (standard or round) Allen bits, or standard 2.5, 3, and 6 mm
Allen wrenches
A round-head Allen bit allows the bit to work at an angle instead of only straight out, which is
helpful in tight spots.
Manual screwdrivers, Phillips and flat head types
Metric wrenches, 10 to 15 mm
Masking tape
Laptop computer attached to the network
The two left PDUs on the left accessory cabinet
The single right PDU on the right accessory cabinet
The auxiliary control unit on the center display structure
Chapter 9, "Routing Power and Signal Cables"
Chapter 8, "Assembling the Remaining Cisco TelePresence Elements"
Chapter 12
for additional information.
for additional information.
