Chapter 12 Field-Replaceable Unit Guide
Step 6 Remove the codec from the Display structure.
Remove the L brackets from the codec.
Step 7
See Chapter 8, "Assembling the Remaining Cisco TelePresence Elements"
Remove the cable management bar from the codec. Retain the bar and the screws.
Step 8
See Chapter 8, "Assembling the Remaining Cisco TelePresence Elements"
Make a note of the MAC address of the new primary codec. The MAC address should be printed on a
Step 9
sticker on the codec. You configure Cisco Unified Communications Manager to use the new MAC
address in the
Attach the L-brackets and Cable management bar to the replacement codec.
Step 10
See Chapter 8, "Assembling the Remaining Cisco TelePresence Elements"
Attach the new codec to the display structure front feet using the screws that you removed in
Step 11
Turn the codec power switch to the On position.
Step 12
Caution
Reattach the cables according to your temporary masking tape identification.
Step 13
See Chapter 9, "Routing Power and Signal Cables"
Attach the cables to the cable management bar using tie wraps.
Step 14
If the replacement unit was the Primary codec, follow these steps to reset the MAC address in
Step 15
Cisco Unified Communications Manager:
Open a browser on a computer connected to the network.
a.
Access the Cisco Unified Communications Manager interface.
b.
Change the MAC address for the Primary codec to its new address.
c.
Power on the system by completing the steps in the
Step 16
Refer to the
information.
Perform the Auto Adjust camera setup procedure. This sets the white balance to the correct levels. See
Step 17
the "Setting Up the Cameras" section on page 10-6
If you are replacing the primary codec, power it on and complete all steps before powering on the
Note
secondary codecs. This prevents the secondary codecs from being affected by any software and
peripheral upgrades to the primary codec.
OL-14521-01
Replacing a Codec Unit—Part Number CTS-CODEC-PRI-G2 (Primary Codec) or CTS-CODEC-SEC (Secondary Codec)
"Powering On the System" section on page
Make sure each PDU power switch is still in the Off position.
Cisco TelePresence System Administrator's Guide
for additional information.
for additional information.
12-1.
for additional information.
for additional information.
"Powering On the System" section on page
for your software release for more
for detailed instructions.
Cisco TelePresence System 3200
Step 5.
12-1.
