Chapter 6 Building the First Row Table Assembly
Step 3 Assemble the I/O modules for the outside left and outside right molded foam bumpers.
The outside left and outside right molded foam bumpers only have one I/O module each. The inner
molded foam bumpers have two (see
Figure 6-3
Steps for routing the Ethernet and power cables are in
Note
The flange on the I/O module cover place is wider on the bottom than on the top.
Note
OL-14521-01
Figure
Foam Bumper Assembly
21
18
25
19
20
6-4).
22 23 24
Chapter 9, "Routing Power and Signal Cables."
Cisco TelePresence System 3200
Parts List
6-5
