Chapter 2
Building the Display Assembly
Parts List
Step 2
Attach the Codec Safety trays to the Front Foot stabilizers.
If you ordered a Presentation Codec, attach the larger tray that comes with the Presentation Codec
Note
package, part no. 700-25301-01, in the center display. Refer to the
Cisco TelePresence Hardware
Options and Upgrade Guide
for more information.
Figure 2-2
Codec Safety trays
12
11
8
Cisco TelePresence System 3200
2-3
OL-14521-01
