Chapter 7
Building the Second Row Table Assembly
Parts List
Step 30
Attach the panel end brace to the table leg and left tabletop end and attach the table leg to the tabletop
and tabletop end.
Figure 7-30
Panel End Braces, Table Leg, Left Tabletop End and Table Section 5
35
21
35
35
Cisco TelePresence System 3200
7-33
OL-14521-01
