Parts List
Output receptacles cannot exceed 15A for any one receptacle.
Warning
Correct routing of the various power cords to the appropriate PDU is critical for the safety and success
Caution
of the Cisco TelePresence System 3200 assembly. Each PDU is routed to a different 20A circuit to
prevent circuit overload when all the electrical components are properly installed. PDUs should be
plugged into their correct wall receptacles as required in the following table.
Left PDU 1
(Located on Left Accessory Cabinet.)
Left PDU 2
(Located on Left Accessory Cabinet.)
Right PDU
(Located on Right Accessory Cabinet.)
First Row Table PDU
(Located above the projector under the Center
table segment.)
Second Row Table left-center PDU
Second Row Table right-center PDU
For cable routing for the second row table, see
Note
Cisco TelePresence System 3200
9-2
Chapter 9
Left 20A AC wall outlet
Center left 20A AC wall outlet
Center right 20A AC wall outlet
Right 20A AC wall outlet
20A AC wall outlet
20A AC wall outlet
Chapter 7, "Building the Second Row Table Assembly."
Routing Power and Signal Cables
