Chapter 12 Field-Replaceable Unit Guide
Step 6 If you are replacing the left or right tabletop end, remove the privacy panel end piece and panel end
brace. See
locations.
Step 7 Remove the privacy panel hangers from the table legs that support the table top section to be replaced.
See Chapter 7, "Building the Second Row Table Assembly"
points and screw locations.
Remove the floating bracket on each side of the table top section to be replaced.
Step 8
See Chapter 7, "Building the Second Row Table Assembly"
and screw locations.
Remove the gutter panel for the table top section to be replaced.
Step 9
See Chapter 7, "Building the Second Row Table Assembly"
screw locations.
Remove the gutter and privacy panel support brackets from the table legs that support the table top
Step 10
section to be replaced.
See Chapter 7, "Building the Second Row Table Assembly"
privacy panel support brackets.
Remove the screws from the table legs that support the table top section.
Step 11
Move one of the table legs to allow access to the draw bolts and remove the draw bolts from the adjoining
Step 12
table top sections. See
draw bolts.
Make sure that the leg still supports both table top sections.
Note
If you are replacing an end piece, remove the attachment plates.
Step 13
If required, reposition the table leg so that it fully supports both table sections.
Step 14
Move the table leg on the other side of the table top to allow access to the draw bolts and remove the
Step 15
draw bolts from the adjoining table top sections.
Make sure that the leg still supports both table top sections.
Note
Separate the table top sections to create a space between the section to be replaced of approximately one
Step 16
inch (2.5 centimeters); this step allows you to remove the splines between the table top sections.
To ease movement of the sections, you can place furniture sliders under each table leg before you move
Tip
the sections.
Be sure that the legs support all table top sections and do not allow any of the sections to fall to the
Caution
ground.
Remove the splines from the slot in the edges of the table top section.
Step 17
Remove the table top section to be replaced.
Step 18
Place the new table top section on the table legs.
Step 19
OL-14521-01
Figure 7-47 for the privacy panel end piece locations and
Chapter 7, "Building the Second Row Table Assembly"
Replacing a Second Row Table Top Section
Figure 7-30 for the panel end brace
for the privacy panel hanger attachment
for the floating bracket attachment points
for the gutter panel attachment points and
for the screw locations for the gutter and
for the location of the
Cisco TelePresence System 3200
12-25
