39.
During slide cutting operation, the saw must be pushed and slided away
from the operator.
40.
Take all the possibility of residual risks in cutting operation into your
consideration, such as the laser radiation to your eyes, the inadvertent
access to moving parts on slide mechanical parts on machine and so on.

SPECIFICATIONS

Max. Cutting
Capacity
Bevel
Height × Width
Compound
Saw Blade Dimensions (oD × iD × Thickness)
Miter Cutting Angle
Bevel Cutting Angle
Compound Cutting Angle
Voltage (by areas)*
Power Input*
No-Load Speed
Machine Dimensions (Width × Depth × Height)
Weight (Net)
Laser Marker
(Only Model C8FSHE)
* Be sure to check the nameplate on product as it is subject to change by areas.
When cutting the workpiece which has the dimension of "**" there might be some possibility of the lower end of the circular saw to touch with the workpiece, even if
the motor head is located at the lower limit position. Pay attention when cutting the workpiece. For further details, refer to "PRACTICAL APPLICATIONS". Mount the
auxiliary board on the fence surface (Refer ( ) the thickness of auxiliary board). Refer to "12. Cutting large workpieces" (Fig. 16).

STANDARD ACCESSORIES

(1) 216 mm TCT Saw blade (mounted on tool) .................................................. 1
(2) Dust bag ........................................................................................................... 1
(3) 10 mm Box wrench ......................................................................................... 1
(4) Vise Assembly ................................................................................................. 1
(5) Holder ............................................................................................................... 1
(6) Side Handle ...................................................................................................... 1
Standard accessories are subject to change without notice.
OPTIONAL ACCESSORIES (SOLD SEPARATELY)
(1) Extension Holder and Stopper
(2) Saw blade 216 mm TCT Saw blade (Total teeth: 60)
(3) Crown molding Vise Ass'y (Include Crown molding Stopper (L))
(4) Crown molding Stopper (L)
(5) Crown molding Stopper (R)
(6) Sub Fence
Optional accessories are subject to change without notice.
Miter 45°
Left 45°
Right 5°
Bevel (Left) 45° + Miter 45°
Bevel (Right) 5° + Miter 45°
Bevel (Left) 0° – 45°
Bevel (Right) 0° – 5°
Maximum output
(Iambda)
Laser medium
65 mm × 312 mm
**75 mm × 262 mm with aux. board (30 mm)
65 mm × 220 mm
**75 mm × 185 mm with aux. board (20 mm)
45 mm × 312 mm
**50 mm × 252 mm with aux. board (30 mm)
60 mm × 312 mm
**70 mm × 252 mm with aux. board (30 mm)
45 mm × 220 mm
**50 mm × 170 mm with aux. board (30 mm)
60 mm × 220 mm
**70 mm × 170 mm with aux. board (30 mm)
216 mm × 30 mm × 2 mm
Right 0° – 57°, Left 0° – 45°
Right 0° – 5°, Left 0° – 48°
Miter (Right and Left) 0° – 45°
(110 V, 230 V)
555 mm × 790 mm × 485 mm
15 kg (C8FSHE) / 14 kg (C8FSE)
Po<3 mW Class
APPLICATION
Cutting various types of aluminium sash and wood.
UNPACKING
Carefully unpack the power tool and all related items (standard accessories).
Check carefully to make certain all related items (standard accessories) are
present.

PRIOR TO OPERATION

1. Power source
Ensure that the power source to be utilized conforms to the power
requirements specified on the product nameplate.
2. Power switch
Ensure that the power switch is in the OFF position. If the plug is connected
to a receptacle while the trigger switch is in the ON position, the power tool
will start operating immediately, inviting serious accident.
English
1050 W
–1
5500 min
Laser Product
654 nm
Laser Diode
14
