6.3.4 (SELECT:) Info

INFO: Rem

1:1
(SELECT:) Info provides the 'read only' status windows that display information on the current
modem configurations without risking inadvertent changes. Select Rem, Tx, Rx, 1:1, Intfc1, or
Intfc2 using the
INFO: Rem
Remote M&C: 100BaseTx
010.006.030.139
This display provides the status, as applicable, of the Remote Monitor & Control configuration.
If the modem is in Remote Mode, the physical interface type (RS232, RS485-2W or RS485-4W),
device address and baud rate will be displayed as follows:
Remote M&C: RS232
Address: 0000
If the modem is in Ethernet Remote Mode, the display will similar to what follows:
Remote M&C: 100BaseTx
IP Addr: 010.006.030.177
INFO: Tx
0000.0000 000.000000 TUR
64
This display provides Tx information, similar to what is shown above. The following information
is provided:
Top Line:
Tx Frequency Data Rate
FEC Encoder
Bottom line:
Modulation Type
Code Rate
Scrambler State
Clocking Mode
Output Power
Tx Output State
TSI State
Tx Rx
Intfc1 Intfc2
◄ ►
arrow keys. Press
9600 Baud
7/8 S -24.9 OF N
.
ENTER
Composite Tx Data Rate
TUR = Turbo
Q= QPSK, 8=8-PSK, 16=16-QAM, or 64=64-QAM
3/4, 7/8
S = Scrambler On, N = Scrambler Off
INT = Internal, EXT = External, LOP = Loop
Level
ON = on, OF = Off, EO = external off
1 = Transmit Spectral Inversion on, N = Off
6–61
