Modules
This section describes the modules designed for the HP 9304M and HP 9308M routing switches.
Chassis Modules
Chassis modules include these options:
•
Redundant Management:
•
8-port Gigabit LX redundant management modules
•
8-port Gigabit SX redundant management modules
•
0-port redundant management module
•
Management
•
16-port 10/100BaseTX management module
•
8-port Gigabit SX management module
•
4-port Gigabit LX and 4-port gigabit SX management module
•
Non-Management
•
8-port 1000Base-T module
•
24-port 10/100BaseTX module
•
24-port 100Base FX (MT-RJ) module
•
8-port Gigabit SX module
•
8-port Gigabit 4LX/4SX module
•
8-port Gigabit LX module
NOTE: The Chassis devices support 1000BaseSX, 1000BaseLX, and 1000BaseT ports.
Redundant Management Module
The Redundant Management modules provide increased route capacity for routing switches running Border
Gateway Protocol Version 4 (BGP4). In addition, the Redundant Management modules contain a configurable
temperature sensor that sends a Syslog message and SNMP trap if the temperature on the module exceeds a
specified warning level. The temperature sensor also can shut the module down automatically to prevent
damage.
You can use one or two Redundant Management modules in a Chassis device. Using two Redundant
Management modules adds fault protection against system outage. The two modules work together as active and
standby management modules. If the active module becomes unavailable, the standby module automatically
takes over system operation.
For more information and complete configuration and management information, see "Using Redundant
Management Modules" on page 5-1.

AC Power Supply

The fixed-port HP 6208M-SX switch and HP 6308M-SX routing switch are equipped with an autoranging 100-250
VAC power supply rated at 5 – 2.5A and 50 – 60 Hz.
The HP 9304M and HP 9308M routing switches are equipped with an autoranging 100 – 120/200 – 240 VAC
power supply rated at 8A/4A and 50 – 60 Hz. The green LED on the power supply is lit when the power supply is
properly supplying 5-volt power to the system.
Hardware Overview
8 - 11
