Installation and Getting Started Guide

Configuration Considerations

You can use one or two redundant management modules in a Chassis device.
You cannot use older management modules in the same Chassis device with redundant management
The flash code (system software) image file for a device running the redundant management modules is
different from the flash code for systems running older management modules. The flash code for redundant
management modules begins with "H2R". If your flash code does not start with "H2R" then you cannot use
the module as a redundant management module.

Temperature Sensor

The redundant management modules contain a temperature sensor. You can use the CLI or Web management
interface to display the active redundant management module's temperature and to change the warning and
shutdown temperature levels. See "Temperature Sensor" on page 5-16.


When you power on or reload an HP 9304M or HP 9308M Chassis device that contains two redundant
management modules, the active redundant management module is selected based on the chassis slot
previously specified by you or according to the lower slot number.
After the active module is selected, the active module loads its boot and flash code (boot and system software)
and its system-config file and manages the system. The standby module also boots, using its own boot code but
using the active module's flash code and system-config file. The standby module monitors the heartbeat of the
active module. If the active module becomes unavailable, the standby module notices the absence of the
heartbeat and assumes management control of the system.
NOTE: By default, the system does not use the boot code on the active module to boot the standby module. If
you upgrade the boot code on the active module and the code contains a problem, you can still use the system by
running the older boot code that is on the standby module. You can configure the standby to synchronize with the
active module's boot code. See "File Synchronization Between the Active and Standby Redundant Management
Modules" on page 5-10.
The standby module's system-config file is updated whenever the system-config file on the active module is
updated. In addition, the running-config file on the standby module is updated at regular intervals to match the
active module's running-config data. Thus, when a switchover occurs, the standby module also can reinstate the
configuration data in the active module's running-config.
Following this switchover to the standby module, the standby module becomes the active module and continues
to manage the system. When the other redundant management module (the one that used to be the active
module) becomes available again or is replaced, that module becomes the standby module.
The active module also monitors the standby module. If the standby module becomes unavailable, the active
module tries to reboot the standby module. You can display the status of each module using the CLI or the Web
management interface, as described in "Determining Redundant Management Module Status" on page 5-7.

Management Sessions

You can establish management sessions only with the active redundant management module, not with the
standby redundant management module. During switchover, all the CLI and Web management interface sessions
open on the system are closed. To manage the system following a switchover, you must open a new
management session. Although the system's MAC addresses change following switchover, the IP addresses do
not. You can open new management sessions on the same IP addresses you were using before the switchover if
To establish a serial connection to the CLI, you must move the serial cable to the serial port on the active
redundant management module.
5 - 2
