Thresholds reversed bar graph
First threshold
Maximum graph value
04/19/95 00:30 AM
Custom Reports: Historical: split status

Save the bar definition

Select the Save action list option.
The Bar window closes, and Successful is displayed in Screen Painter status line to
indicate the bar definition has been added.
To define additional bars, repeat task 1
through task 9
Note:
Note:
Second threshold
Avaya(TM) CMS
..............................................
..............................................
..............................................
Normal.
Caution.
(bar is dim
(bar is bright
intensity or green.)
intensity or yellow.)
(Select normal or reversed thresholds
You must assign a Row Search ID to the bar before your field definition is
complete. When you do, the question mark (?) changes to that ID number.
See Defining the rows of data for a report
If a bar will be a repeated bar (as defined with the Row Search window), you
cannot define any other bars in the direction that the bar will repeat. That is,
if the bar will be repeated vertically, no other bars (or text or fields) can are
displayed directly below the bar. If the bar will be repeated horizontally, no
other bars (or text or fields) can be displayed directly to the right of the bar.
Windows: 1 of 5 ^
Row 1 Col 1
Warning.
(bar is blinking
dim/bright intensity
or red.)
(Define the position and length of a bar
on page 86).
on page 88 .
Defining bars in a report
on page 82)
Issue 3.0 May 2002 87
