Bind FXO ports to higher layer applications

An FXO port needs to be associated to an fxo interface in a CS context. The same mechanism of encapsulation
and binding is used as known for e.g. ethernet ports (see section
Procedure: To bind an FXO port to an fxo interface of a CS context
Mode: Port FXO
Step 1 node (config)#port fxo slot port
Step 2 node (prt-fxo)[ slot / port ]#encap-
sulation cc-fxo
node (prt-fxo)[ slot / port ]#bind
Step 3
interface interface
Configure country specific FXO port parameters
Unlike ISDN, POTS is heavily country specific even though there is a good chance that a setting for one coun-
try works reasonably good in another country. Country specific settings are contained in a so-called fxo profile
which is integrated in the firmware of the SmartNode. It can be updated independently from the firmware by
means of tftp download.
As there are over 190 countries SmartWare of course does not support all different country parameters. Thus
before operation make sure that the country parameter for your country is available as profile.
Procedure: Configure country specific FXO parameters
Mode: Port FXO
Step 1 node (config)#port fxo slot port
Step 2 node (prt-fxo)[ slot / port ]#use
profile fxo profile

Bind FXO ports to higher layer applications

Command
Command
"Interfaces, Ports, and Bindings"
Purpose
Enter configuration mode for FXO port
Sets the encapsulation for the port. cc-fxo designs
the encapsulation is a context CS interface
Binds the port to an interface in a CS context
Purpose
Enter configuration mode for FXO port
Select a profile containing the country specific set-
tings of the port. Available profiles are:
'etsi' according to ETSI standard
•
'fcc68_25Hz' for the United States of America /
•
Canada, according to the FCC86 standard,
with 25Hz ringing detection.
• 'fcc68_50Hz' for the United States of America /
Canada, according to the FCC86 standard,
with 50Hz ringing detection.
• 'tbr21_25Hz', according to the TBR 21 stan-
dard, with 25Hz ringing detection.
• 'tbr21_50Hz', according to the TBR 21 stan-
dard, with 50Hz ringing detection.
The default profile (not displayed in the list when
entering the command) is etsi.
37 • FXO port configuration
on page 38).
