SmartWare Software Configuration Guide

Using the AdventNet SNMP utilities

The AdventNet SNMP utilities are a set of cross-platform applications and applets for SNMP and Web-based
network management. These utilities can be used for device, element, application and system management.
The tools can communicate and interact with any SNMP enabled device, such as a SmartNode 1000, 2000 or
4000 series device. The following tools are the most useful part of the product for SmartNode 1000, 2000 or
4000 series device management:
• MibBrowser—used to view and operate on data available through a SNMP agent on a managed device
• TrapViewer—used to parse and view the received traps
The AdventNet MibBrowser is a complete SNMP MibBrowser that enables the loading of MIBs, MIB brows-
ing, walking a MIB tree, searching MIBs and performing all other SNMP-related functions to users.
Viewing and operating the data available through an SNMP agent on a managed device, e.g. a router, switch,
hub etc., is made possible by using the MibBrowser.
The TrapViewer is a graphical tool to view the Traps received from one or more SNMP agents. The Trap viewer
can listen to one or more port at a time and the traps can be sent from any host. Moreover the TrapViewer con-
tains a Trap parser editor, which is a tool to create a trap parser file. The Trap viewer parses the file created using
Trap parser editor to match each incoming traps with certain criteria. Since Traps typically contain cryptic
information, which is not easily understandable to the users, trap parsers are required to translate or parse traps
into understandable information.

Using the MibBrowser

Figure 44 depicts the primary window of the AdventNet MibBrowser. It consists of a menu bar, a toolbar, a left
frame and a right frame.
The operations that can be performed by the MibBrowser are available in a series of buttons in the toolbar on
top of the MibBrowser's main window. The toolbar can be hidden or made visible using the options available.
The menu bar has various options that perform the same operations as the options available in the toolbar.
The left frame holds the MIB tree. A MIB tree is a structure through which all the MIBs loaded can be viewed.
The MIB tree component enables us to traverse through the tree, view the loaded MIBs and learn the definition
for each node. The AdventNet MibBrowser allows loading additional MIB files in the text format, e.g. the Patton
Electronics Co. enterprise specific MIBs used for SmartNode 1000, 2000 or 4000 series device management.
The right frame has labeled text fields to specify the basic parameters like host, community etc. and a Result
text area display to view the results.
There are three ways in which the primary window of the MibBrowser can be viewed. It can be viewed with
the result display, MIB description panel or multi-variable bind panel in the right frame. The view can be
altered in three ways.
• The desired view can be set by the options provided in the display menu item under the view menu.
(View Display
• The other way of altering the view is through the general settings panel in the settings menu item in the edit
menu. (Edit ‡ Settings)
