37 • FXO port configuration

Other FXO port parameters

This section describes the commands available for the configuration of an FXO port.
Procedure: Configure the FXO port parameters
Mode: Configure
Step 1 node (config)#port fxo slot port
Step 2 node (prt-fxo)[ slot / port ]#caller-id for-
optional mat { bell | etsi }
Step 3 node (prt-fxo) [ slot / port ]#flash-hook
duration duration
optional
450
Command
SmartWare Software Configuration Guide
Purpose
Enter FXO port configuration mode
Specifies which line protocol is used for caller-id
transmission. Use bell for US / Canada, etsi for
Europe.
If caller-id is not enabled or wrong configured,
detection of caller-id is not possible. Default: etsi
Specifies for what time the SmartNode should go
on-hook to signal flash-hook to the CO. Default of
duration is 200ms, for US and Canada try 350ms
or higher.
