13 • Ethernet port configuration
This procedure describes how to configure the medium for the Ethernet port on slot and port
Mode: Configure
Step
1 node (cfg)#port ethernet slot port
2 node (prt-eth)[ slot/port ]#medium (10 |
100 | auto} (half | full)
Note The following restrictions apply:
•
SN1x00: Both Ethernet ports support 10 Mbps half-duplex
•
SN2300: Ethernet port 0/1 only supports 10 Mbps half-duplex, other set-
•
SN4xxx: Ethernet port 0/1 supports 10 Mbps half-duplex.
Example: Configuring medium for an Ethernet port
The following example shows how to configure medium auto-sense for the Ethernet port on slot 0 and port 0
of a SmartNode 4524 device.
SN(cfg)#port ethernet 0 0
SN(prt-eth)[0/0]#medium auto
Configuring Ethernet encapsulation type for an Ethernet port
This procedure describes how to configure the encapsulation type to IP for the Ethernet port on slot and port.
Mode: Configure
Step
1 node (cfg)#port ethernet slot port
2 node (prt-eth)[ slot/port ]#encapsulation ip
Example: Configuring Ethernet encapsulation type for an Ethernet port
The following example shows how to configure the encapsulation type to IP for the Ethernet port on slot 0 and
port 0 of a SmartNode 1000, 2000, or 4000 series device.
SN(cfg)#port ethernet 0 0
SN(prt-eth)[0/0]#encapsulation ip

Binding an Ethernet port to an IP interface

You must bind the Ethernet port to an existing IP interface. When executing the bind command, the requested
interface must exist. If no IP context is given, the system attaches the interface to the default IP context known
as router.
144
Command
tings are ignored
Command
SmartWare Software Configuration Guide
Purpose
Enters Ethernet port configuration mode for the
interface on slot and port .
Configures the interface on slot and port to
medium according to the selected option.
Purpose
Enters Ethernet port configuration mode for the
interface on slot and port .
Configures the encapsulation type to IP.
Ethernet port configuration task list
