17 • RIP configuration
Example: Enabling send RIP
The following example shows how to enable send RIP on IP interface wan on a SmartNode.
SN(cfg)#context ip router
SN(ctx-ip)[router]#interface wan
SN(if-ip)[wan]#rip supply

Enabling an interface to receive RIP

By default an interface does not listen to routing information. This procedure describes how to enable interface
to receive RIP information
Mode: Interface
Step
1 node (if-ip)[ name ]#rip receive
Example: Enabling receive RIP
The following example shows how to enable receive RIP on IP interface wan on a SmartNode.
SN(cfg)#context ip router
SN(ctx-ip)[router]#interface wan
SN(if-ip)[wan]#rip receive

Specifying the send RIP version

By default, SmartWare application software sends RIP 1compatible packets. The SmartWare application soft-
ware allows sending RIP version 1, version 1 compatible or version 2 packets. Alternatively, you can explicitly
configure the RIP version to be sent with the last command argument as following:
• 1—RIPv1
• 1compatible—RIPv1 compatible
• 2—RIPv2
This procedure describes how to select the sending RIP version on interface
Mode: Interface
Step
node (if-ip)[ name ]# rip send version {1 | 1compatible | 2} Selects send RIP version for inter-
1
Example: Specifying the send RIP
The following example shows how to select send RIP version 1compatible on IP interface wan on a SmartNode.
SN(cfg)#context ip router
SN(ctx-ip)[router]#interface wan
SN(if-ip)[wan]#rip send version 1compatible
196
Command
Command
SmartWare Software Configuration Guide
Purpose
Enables receive RIP on interface name
face name
Purpose
RIP configuration task list
