SmartWare Software Configuration Guide
Fax transmission modes are organized the same way codecs are: there is an ordered list of fax transmission
modes; the most preferred fax transmission mode is the first one in the list.
Procedure: Configure fax bypass
Mode: Profile VoIP
Step
1 node (pf-voip)[ name ]#fax transmis-
sion bypass g711alaw64k
2 node (pf-voip)[ name ]#fax dejitter-
max-delay buffer-size
optional
Procedure: Configure fax relay (T.38)
Mode: Profile VoIP
Step
1 node (pf-voip)[ name ]# fax transmis-
sion relay t38-udp
2 node (pf-voip)[ name ]#fax
(optional) redundancy ls low-speed-redundancy hs
high-speed-redundancy
VoIP profile configuration task list
Command
Command
40 • VoIP profile configuration
Purpose
Adds fax bypass transmission with codec G.711
to the list of fax transmission modes.Alternative
codecs available are:
G.711uLaw
•
• G.726 32kbps
G.726 24kbps.
•
Sets the size of the dejitter buffer during fax trans-
missions. The operating mode of the dejitter buffer
is automatically set to fax optimized static-data
mode.
Patton recommends that you keep the size for fax
transmissions higher than that used for voice, since
fax is less sensitive to delay than packet loss.
The default value is 200ms which should be nomi-
nal for almost any transmission network. In excep-
tional cases it may be necessary to increase this
value (maximum 400ms).
Purpose
Adds fax relay transmission with T.38 protocol
over UDP to the list of fax transmission modes.
Packet loss can be avoided by transmitting the fax
data packets several times. This can be configured
separately for low speed and the high speed traf-
fic. The default for both parameters is 0 (no redun-
dant transmission). Note that values greater than 0
provide more reliable transmissions, but consume
additional bandwidth.
