SmartWare Software Configuration Guide
lines) commands. For example, you need bind commands to bind a physical port to a logical interface, and use
commands to assign profiles to contexts.
The sections that follow refer to
detail.

Contexts and Gateways

Context

A SmartWare context represents one specific networking technology or protocol, namely IP (Internet Protocol)
or CS (circuit-switching). A context can be seen as virtual dedicated equipment within the SmartNode. For
example:
• A CS context contains the circuit-switching functions of the SmartNode. It can be thought of as an embed-
ded multiplexer or cross-connect within the SmartNode
• An IP context contains the routing functions of the SmartNode. It can be thought of as an embedded
router within the SmartNode
The contexts are identified by a name and contain the configuration commands that are related to the technology
they represent. A separate configuration can be built by means of the context concept for newly supported net-
work layer technologies without complicating the configuration methods of existing features. For example, as
bridging, ATM, or FR switching becomes available so a bridging, ATM, or FR context can be introduced.
Each context contains a number of interfaces, which build the connections to other SmartWare elements and
the outside world. Figure 7
• one of type IP named router
• one of type CS named switch
This corresponds to the default configuration of all SmartNodes.
Note
SmartWare currently supports only one instance of the CS and IP context types.
Example
The IP context named router can contain static routes, RIP, and NAT configuration parameters. The default
circuit-switching context named switch can contain number translations, local breakout conditions, and least-
cost routing parameters.

Gateway

The concept of a gateway is introduced for the communication between contexts of different types. A gateway
handles connections between different technologies or protocols. For example, an H.323-gateway can connect
an IP context to a circuit-switching context.
The gateways are each of a specific type and are identified by a name. Each named gateway contains its config-
uration parameters. With this concept, a separate gateway can be built for newly-supported technology such as
MGCP or SIP without complicating the configuration methods of existing software parts.
shows two gateways, one of type h323 named h323 and one of type SIP named sip.
Contexts and Gateways
figure 7 on page 36 and describe the concepts and elements in more
on page 36 shows two contexts:
2 • Configuration concepts
Figure 7 on page 36
