38 • H.323 gateway configuration
172.16.224.102(gw-h323)[h323]#h235security general-id GK01
172.16.224.102(gw-h323)[h323]#h235security ras-auth-int-tx
172.16.224.102(gw-h323)[h323]#h235security ras-auth-int-rx
172.16.224.102(gw-h323)[h323]#h235security q931-auth-int
172.16.224.102(gw-h323)[h323]#show h235security
H.235 SECURITY SETTINGS
-----------------------
H.235 Security
H.235 Module Version
H.235 Version
Sender ID
General ID
Time Window
Master Password Hash
Debug Monitor:
172.16.224.102(gw-h323)[h323]#
172.16.224.102(gw-h323)[h323]#debug h235security detail 3
172.16.224.102(gw-h323)[h323]#h235security
172.16.224.102(gw-h323)[h323]#14:27:35
Advanced configuration options (optional)

Enabling H.245 Tunneling

If H.245 Tunneling is enabled, H.245 messages use the same TCP connection as the H.323 signaling. H.245
Tunneling is disabled by default. If enabled, it only takes place when both parties agree. When experiencing
problems with establishing H.323 calls, disabling H.245-Tunneling may help.
Mode: Gateway H.323
Step
1
node (gw-h323)[h323]#h245-tunneling
Example: Enabling H.245 tunneling
The following example shows how to enable H.245 tunneling on an already defined H.323 Gateway.
SN(cfg)#gateway h323 h323
SN(gw-h323)[h323]#h245-tunneling]

Enabling the fastconnect procedure

If the fastconnect procedure is enabled, no separate H.245 connection is opened and all media channel specific
messages are carried within the H.225 call signaling connection. Fastconnect is disabled by default. If enabled,
it only takes place when both parties agree. Fastconnect can be enabled using the following procedure:
Mode: Gateway H.323
Step
1
node (gw-h323)[h323]#faststart
460
: Disabled
: 2.02.01
: 2
: NODE13
: GK01
: 100 seconds
: bc210d2244a1afd2e7da7a54a1a8c179403220c4
: Disabled
Command
Command
SmartWare Software Configuration Guide
H235 > Info: H.235 was started successfully
Enables H.245 tunneling.
Enables the fastconnect procedure.
Purpose
Purpose
