SmartWare Software Configuration Guide

Introduction

This chapter provides an overview of POTS signaling and SmartNode FXO ports and describes the tasks
involved in configuring FXO ports in SmartWare.
This chapter includes the following sections:
• Shutdown and enable FXO ports (see
• Bind FXO ports to higher layer protocols (see
• Configure country specific FXO port parameters (see
• Configure other FXO port parameters (see
FXO stands for foreign exchange office and is the subscriber side of a POTS (plain old telephone system) line.
An FXO port on the SmartNode simulates thus an analog phone set, which must actively go on-hook and off-
hook, detect ringing and caller-id, and dial the called-party number using DTMF keypad.

Shutdown and enable FXO ports

FXO ports are enabled by default. They also can be configured when they are active. But keep in mind that
configuration of an active port temporarily disables the port for a short time (some milliseconds).
Mode: Configure
Step Command
1 (config)#port fxo slot port
2 (prt-fxo)[slot/port]#shut-
down
3 (prt-fxo) [slot/port]#no shut-
down

Bind FXO ports to higher layer applications

An FXO port needs to be associated to an fxo interface in a CS context. The same mechanism of encapsulation
and binding is used as known for e.g. ethernet ports (see section
Procedure: To bind an FXO port to an fxo interface of a CS context
Mode: Port FXO
Step
1 node(config)#port fxo slot port
2 node(prt-fxo)[slot/port]#encap-
sulation cc-fxo
3 node(prt-fxo)[slot/port]#bind
interface interface
Introduction
page 538)
page
page 539)
Enter FXO port configuration mode
Shutdown the port. All active calls are dropped!
Activate the port.
Command
539)
page 539)
Purpose
"Interfaces, Ports, and Bindings"
Purpose
Enter configuration mode for FXO port
Sets the encapsulation for the port. cc-fxo designs
the encapsulation is a context CS interface
Binds the port to an interface in a CS context
44 • FXO port configuration
on page 47).
