34 • Tone configuration
If the user has not specified a tone-set profile, the default tone-set will be taken to generate the local inband
information. For enabling a user defined tone-set profile on a specific interface proceed as follows.
Procedure: To assign a tone-set profile to a PSTN interface
Mode: Interface
Step
1
node (ctx-cs)[switch]#interface if-type if-
name
2
node (if- type )[ if-name ]#use profile tone-
set name
Example: Assign tone-set profiles to an ISDN interface
The example shows how to use the SWISS tone-set for the CS context, and use the USA tone-set for an indi-
vidual interface.
SN(cfg)#context cs
SN(ctx-cs)[switch]#interface isdn bri0
SN(if-isdn)[bri0]#use profile tone-set USA
Show call-progress-tone and tone-set profiles
Use the show commands to display the call-progress-tone profiles as well as the tone-set profiles.
Procedure: To show call-progress-tone profiles
Mode: Administrator execution
Step
1 node #show profile call-progress-tone
[ name ]
Example: Show call-progress-tone profile
The following example shows how to display the call-progress-tone profiles.
SN#show profile call-progress-tone belgianSpec
Profiles:
---------
belgianSpec:
Play 330ms (950Hz at -4dB)
Play 330ms (1400Hz at -4dB)
Play 330ms (1800Hz at -4dB)
Pause 100ms
Procedure: To show tone-set profiles
422
Command
Command
SmartWare Software Configuration Guide
Purpose
Enter interface configuration mode.
Assign a user defined tone-set profile to an
interface.
Purpose
Display all call-progress-tone profiles or a spe-
cific with name name
Tone configuration task list
