Entering the Ethernet port configuration mode
To enter port configuration mode and begin configuring an Ethernet port, enter the command port ethernet
slot port in administrator execution mode. The keywords slot and port represent the number of the respective
physical entity as show in
Table 6. Permanent built-in interface slot and port mapping for SmartNode 1x00, 2x00, and 4xxx Series
Device Type
SmartNode 1x00
SmartNode 2x00
SmartNode 4xxx
a. Available on 45xx only
Since a port must be configured unambiguously, choose the appropriate expansion slot and port number. The num-
ber and type of available ports depend upon your SmartNode model, and also on the interface card fit for Smart-
Node 2000 series devices. All permanent on-board interfaces of a SmartNode are described as being on slot 0.
Configuring medium for an Ethernet port
All Ethernet ports are configured by default to auto-sense both the port speed and the duplex mode. This is the
recommended configuration. Supported command options are:
• 10—for 10 Mbps
• 100—for 100 Mbps
• auto—for auto-sense the port speed
• half—for half-duplex
• full—for full-duplex
Ethernet port configuration task list
table 6.
Interface Type
Ethernet
ISDN
Ethernet
Serial (SN2300 only)
Ethernet
FXS
13 • Ethernet port configuration
Slot Port
0 0
1
0 0
1
0 0
1
0 0
0 0
1
0 0
...
7 (max)
Interface
ETH 0
ETH 1
BRI 0
BRI 1
ETH 0/0
ETH 0/1
SERIAL 0/0
ETH 0/0
a
ETH 0/1
FXS 0/0
...
FXS 0/7
