30 • FXO interface configuration
Now we can apply the PSTN profile for the FXO interface named name as follows.
Step Prompt, command & response
6 node(if-fxo)[if-name]#[no] use profile pstn profile-name The "profile pstn" command is
node(if-fxo) [if-name] #
Configuring when the digits are dialed (optional)
When the FXO port goes off-hook to make an outgoing call, the FXS switch normally sends a dial-tone to
indicate it is ready to received dialed digits. Alternatively, you can specify the FXO interface to wait a specific
period of time after going off-hook before dialing the first digit.
Note
All countries do not have the same dial-tone. For information on configur-
ing the dial-tone for your country, refer to chapter 34,
on page 417.
The default setting is to wait for the dial-tone. Choosing to wait a specific time after dial-tone, the variable is
timeout, the number of seconds to wait. Zero (0) seconds means that the interface dials immediately.
Mode: Interface FXO
Step
1 node>
2 node>enable
node#
3 node#configure
node(cfg)#
4 node(cfg)#context cs
node(ctx-cs)[switch]#
340
Prompt, command & response
SmartWare Software Configuration Guide
Purpose
applied to the FXO interface
named if-name
Response: You are now in the
FXO interface configuration
mode. In this mode, you may con-
figure the parameters for the FXO
interface name .
"Tone configuration"
Purpose
Basic prompt in Operator
Exec mode
Enters Administration execu-
tion mode
Response: The prompt in
administration execution
mode is the #
Enters the Configure configu-
ration mode
Response: The prompt in the
Configure configuration
mode is (cfg)#
Enters the Context CS config-
ure mode
Response: The prompt in the
Context CS configuration
mode is (ctx-cs)[switch]#
FXO interface configuration task list
